TOP-275X Mini IGBT Inverter Welding machine (MMA), Metal case with plastic frame Portable DC Single Phase 220V-230V 120A

Zhejiang Kende Mechanical & Electrical Co., Ltd. Home / Product / IGBT Inverter MMA or Stick Welding Machine / TOP-275X Mini IGBT Inverter Welding machine (MMA), Metal case with plastic frame Portable DC Single Phase 220V-230V 120A

TOP-275X Mini IGBT Inverter Welding machine (MMA), Metal case with plastic frame Portable DC Single Phase 220V-230V 120A

● Hot Start lets you start welds easily

●ARC Force monitors the voltage and provides additional current when needed

●Anti-stick technology allows the user to easily separate the electrodes from the workpiece

●Power Switch lights up to tell you the power is on

● Thermal overload protection with indicator light

●2m welding cable with dual-angle electrode holder

●1.5m ground cable with clamp

●High welding current stability for consistent output

●DC current out provides stable output for good penetration

CONTACT US Zhejiang Kende Mechanical & Electrical Co., Ltd.

Technical Characteristics

●Use powerful IGBT switches and advanced inverter control technology.

●Use digital PI and PWM control technology. Constant Current ( CC ) output control, welding current can be exactly controlled.

●MMA welding process method. Special design of the circuit and structure of these welding power sources.

● Excellent arc characteristics , good welding performance and little spatter.

●Strong ability of the anti-fluctuating of power supply voltage.Under 130~270V, these machines will have output current, and can weld.

●Under longer welding cable , this Machine can weld.

●Minimizing , lightness, it can be moved easily, and energy savings up to 30%.

●With auto protection functions of over current and over-heat.

●The welding material of the thin, medium plate can be welded.

●Be able to weld all kinds of metal, for example, carbon steel, stainless steel, alloy steel, etc.

With complete accessories:

Electrode holder, earth clamp, welding cable, brush/hammer, protective mask.

Specifications

Rated
Supply
Voltage
Supply
Frequency
Rated
Input
Capacity
Rated
Supply
Current
No-Load
Voltage
Welding
Current
Range
Rated
Welding
Voltage
Rated
Duty
CYCLE
Usable electroad Efficiency Power
Factor
Degrees of
Protection
Class of
Insulation
Net
Weight
Machine Size
Technical Characteristics

V

Hz

KVA

A

V

A

V

%



mm

%

Cosφ

IP



kg

mm

TOP-275X 1~220 50/60 6.6 30 62 20-140 25.6 60 1.6-3.2 85 0.9 IP21S H 2.0 230L
105W
135H
