MIG-500Mn, inverter MIG/MAG and MMA function,Can weld ordinary carbon steel, stainless steel, and other materials, MIG/MIG/MAG/No gas shielded Flux wire welding

CONTACT US Zhejiang Kende Mechanical & Electrical Co., Ltd.

Technical Characteristics

Adopting IGBT tube, advanced MCU digital control and soft-switching control technology, it can control the welding process more accurately, reduce spatter and obtain high-quality welds;
It has the functions of manual welding, gas-shielded welding (including CO2 gas-shielded welding and mixed gas-shielded welding), and even carbon arc gas planer operation is no problem, which can meet your various welding requirements. The welding performance is better than ordinary gas shielded welding machine. All this is attributed to the advanced control technology of MIG-500Mn;
It has the functions of gas detection, far or near control setting, solid or flux cored wire and its wire diameter selection; it can set the operation mode of the torch switch; and set the parameters of the three different phases of initial, welding and arc closing. It is convenient for users to choose and control. The operation interface can make the welder's selection and parameter adjustment more intuitive and convenient;
It is easy for welders to set welding parameters and easy to master, so that even welders who have not undergone strict training can obtain high-quality welds;
The parameters of different welding methods are displayed intuitively and can also be set flexibly. It can be changed according to the actual needs;
Suitable for welding of thin, medium and thick plates, with good welding adaptability. Low spatter welding can be realised;
Welding specification parameters can be adjusted independently at the initial stage, welding and arc closing to improve the quality of the weld at the initial stage and arc closing;
The wire feeder is easy to move. 500A current, high load sustaining rate. Suitable for welding stainless steel, carbon steel, alloy steel and other non-ferrous and ferrous materials;
Suitable for flat welding, vertical welding, back welding, horizontal welding and all-position welding; suitable for solid wire and flux-cored wire welding with diameter Ф 1.0, Ф 1.2, Ф 1.6;
Mobile wire feeding mechanism, convenient for long-distance welding operations.

Specifications

Rated
Supply
Voltage		 Supply
Frequency		 Rated
Input
Capacity		 Rated
Supply
Current		 No-Load
Voltage		 Welding
Current
Range		 Rated
Welding
Voltage		 Rated
Duty
CYCLE		 Usable
Wire		 Efficiency Power
Factor		 Degrees of
Protection		 Class of
Insulation		 Net
Weight		 Machine Size
Technical Characteristics

V

Hz

KVA

A

V

A

V

%



mm

%

Cosφ

IP




kg

mm
MIG-500Mn 3~380±15% 50/60 24 36.5 75-85 40-500 39 60 1.0-1.6 85 0.9 IP21S H 39 350L
300W
430H
