MIG-140E/ET 120V ETL digital display portable IGBT inverter welder MIG MAG MMA FLUX 2T 4T VRD Inverter GAS shield 1-5kg wire Welding Machine

Zhejiang Kende Mechanical & Electrical Co., Ltd. Home / Product / MIG/MAG or GMAW / MIG-140E/ET 120V ETL digital display portable IGBT inverter welder MIG MAG MMA FLUX 2T 4T VRD Inverter GAS shield 1-5kg wire Welding Machine

MIG-140E/ET 120V ETL digital display portable IGBT inverter welder MIG MAG MMA FLUX 2T 4T VRD Inverter GAS shield 1-5kg wire Welding Machine

 ●Versatile unit handles MIG/Stick/TIG welding processes

Dual basic/advanced modes allow you to match your welding style

 Multi-voltage operation from 120V/230V power source

 DC only machine (will not TIG weld aluminum)

 Hot start and Arc Force (Stick mode only)

 Lift arc (TIG mode only)

CONTACT US Zhejiang Kende Mechanical & Electrical Co., Ltd.

Technical Characteristics

  • 110V and 230V Two kinds of power supply voltage.Automatically identify and control.
  • The welding machine is made by using advanced MCU, IGBT Inverter and Switching mode power supply control technology.
  • Three welding methods:MIG/MAG/No gas shielded Flux wire welding, MMA and TIG.VRD function under MMA welding.Single knob or SYNERGIC parameters controlling, 2T, 4T, Check gas and Check wire control function under MIG/MAG/No gas shielded Flux wire welding.
  • Can weld thin and medium plate of carbon steel, alloy steel, stainless steel and other materials.
  • The welding process can be exactly controlled by using MCU(Microprocessor Control Unit) control system, welding arc is very stable.
  • Small spatter, good welding performance and weld of high quality.
  • LCD screen display, touch button, encoder parameters adjustment, simple operation.
  • Multiple protective measures, high reliability. strong resistance to power supply voltage changes.
  • High efficiency and energy saving, small volume, light weight, easy to move and beautiful appearance.

Specifications

Rated
Supply
Voltage
Supply
Frequency
Rated
Input
Capacity
Rated
Supply
Current
No-Load
Voltage
Welding
Current
Range
Rated
Welding
Voltage
Rated
Duty
CYCLE
Usable
Wire
Efficiency Power
Factor
Degrees of
Protection
Class of
Insulation
Net
Weight
Machine Size
Technical Characteristics

V

Hz

KVA

A

V

A

V

%



mm

%

Cosφ

IP



kg

mm

MIG-140E/ET 1~120v 60 2.5 20.8 69 30-140 21 30 0.6-1.0 85 0.9 IP21S H 11.5 491L
200W
354H
MIG-170E/ET 1~120v
1~240v
60 6.5 27.2 69 30-170 22.5 15 0.6-1.0 85 0.9 IP21S H 11.7 491L
220W
367H
MIG-200E/ET 1~120v
1~240v
60 7.8 32.5 69 30-220 24 15 0.6-1.0 85 0.9 IP21S H 12 491L
220W
367H
