KD-630G/650G, INDUSTRIAL USE 380-400V, High duty cycle, digital display, easy to start arc, anti sitcker, arc force 500/600A IGBT Inverter Welding machine

Zhejiang Kende Mechanical & Electrical Co., Ltd. Home / Product / IGBT Inverter MMA or Stick Welding Machine / KD-630G/650G, INDUSTRIAL USE 380-400V, High duty cycle, digital display, easy to start arc, anti sitcker, arc force 500/600A IGBT Inverter Welding machine

KD-630G/650G, INDUSTRIAL USE 380-400V, High duty cycle, digital display, easy to start arc, anti sitcker, arc force 500/600A IGBT Inverter Welding machine

Inverter MMA serial own the functions: Arc Force, Hot Start, Anti Stick.
• Hot Start lets you start welds easily
• ARC Force monitors the voltage and provides additional current when needed
• Anti-stick technology allows the user to easily separate the electrodes from the workpiece
• Advanced Microprocessor Control Unit (MCU) digit control and IGBT inverter technology.
• LED Screen Display.
• Strong ability of the anti-fluctuating of power supply voltage
• Excellent arc characteristics, good welding performance and little spatter.
• Under MMA or Stick welding, the DC-LIFT Arc Start method is used.
• With complete accessories:
 Electrode holder, earth clamp, welding cable, brush/hammer, protective mask.

CONTACT US Zhejiang Kende Mechanical & Electrical Co., Ltd.

Technical Characteristics

• Use powerful IGBT switched and advanced inverter control technology
• Use PWM control technology and Constant Current (CC) output control, welding current can Be exactly controlled & adjust continuous in large scale.
• Work properly under 300-480V.
• Excellent arc characteristics and welding performance.With Anti-stick, hot start , arc force.
• Moisture-proof, anti-corrosion, anti-vibration, and anti-conductive dust
• Small size, light-weight, low power consumption, energy saving up to 30%
• With auto-protection functions of over-current and over-heat.
• Be able to weld all kinds of metal, such as carbon steel, alloy steel, cast iron, stainless steel, etc.

Specifications

Rated
Supply
Voltage
Supply
Frequency
Rated
Input
Capacity
Rated
Supply
Current
No-Load
Voltage
Welding
Current
Range
Rated
Welding
Voltage
Rated
Duty
CYCLE
Usable electroad Efficiency Power
Factor
Degrees of
Protection
Class of
Insulation
Net
Weight
Machine Size
Technical Characteristics

V

Hz

KVA

A

V

A

V

%



mm

%

Cosφ

IP



kg

mm

KD-630G 3~380/400V 50/60 33 50 85 40-500 40 60 1.6-5.0 85 0.9 IP21S H 36 630L
330W
590H
KD-650G 3~380/400V 50/60 38 58 85 40-600 44 60 1.6-5.0 85 0.9 IP21S H 37 630L
330W
590H
